# Outline

- Counting
- Relation
- Graphs
- Tree
- P, NP and NPC Problems

# Chapter 11 - Counting

**Basic Counting Rules**： the Product Rule & the Sum Rule

**Pigeonhole Principle**：

If there are more objects than bins then there is at least one bin with more than one object.

**Generalized Pigeonhole Principle**：

If $N$ objects are placed into $k$ bins, then there is at least one bin containing at least $⌈N/k⌉$ objects.

**Inclusion-Exclusion Principle**：

$|A\cup B|=|A|+|B|-|A\cap B|$

$|\bigcup\limits_{i=1}^{n}E_i|=\sum\limits_{k=1}^{n}(-1)^{k+1}\sum\limits_{1\le i_1<i_2<\cdots<i_k\le n}|E_{i_1}\cap E_{i_2}\cap\cdots \cap E_{i_k}|$

**Permutations**：

$P(n,k)=\frac{n!}{(n-k)!}$

**Binomial Coefficient**：

$\left(\begin{array}{c}

n \\

k

\end{array}\right)=C(n, k)=\frac{n!}{k!(n-k)!}$

**Some Properties of Binomial Coefficients**：

$\left(\begin{array}{c}

n \\

k

\end{array}\right)=\left(\begin{array}{c}

n \\

n-k

\end{array}\right)$

$\sum\limits_{i=0}^{n}\left(\begin{array}{c}

n \\

i

\end{array}\right)=2^n$

**Pascal identity**：

$\left(\begin{array}{c}

n \\

k

\end{array}\right)=\left(\begin{array}{c}

n-1 \\

k-1

\end{array}\right)+\left(\begin{array}{c}

n-1 \\

k

\end{array}\right)$

**Pascal’s Triangle**：

$\begin{array}{l}

1 \\

1 \quad 1 \\

\begin{array}{lll}

1 & 2 & 1

\end{array} \\

\begin{array}{llll}

1 & 3 & 3 & 1

\end{array} \\

\begin{array}{lllll}

1 & 4 & 6 & 4 & 1

\end{array} \\

\begin{array}{llllll}

1 & 5 & 10 & 10 & 5 & 1

\end{array} \\

\begin{array}{lllllll}

1 & 6 & 15 & 20 & 15 & 6 & 1

\end{array} \\

\end{array}$

**The Binomial Theorem**：

$(x+y)^n=\sum\limits_{i=0}^{n}\left(\begin{array}{c}

n \\

i

\end{array}\right)x^{n-i}y^i$.

**Trinomial Coefficients**：

When $k_1+k_2+k_3=n$

$\left(\begin{array}{ccc}

& n & \\

k_{1} & k_{2} & k_{3}

\end{array}\right)=\frac{n!}{k_1!k_2!k_3!}$

**The Polynomial Theorem**：

$(a_1+a_2+\cdots+a_m)^n=\sum\limits_{x_1+x_2+\cdots+x_m=n}\frac{n!}{x_1!x_2!\cdots x_m!}a_1^{x_1}a_2^{x_2}\cdots a_m^{x_m}$

**Solving Linear Recurrence Relations of degree 2**：

$a_n=c_1a_{n-1}+c_2a_{n-2}$

characteristic equation: $r^2-c_1r-c_2=0$

If CE has 2 distinct roots $r_1\ne r_2$, the solution: $a_n=\alpha_1r_1^n+\alpha_2r_2^n$

**Solving Linear Recurrence Relations of degree k**：

$a_n=\sum\limits_{i=1}^kc_ia_{n-i}$

CE: $r^k-\sum\limits_{i=1}^k c_ir^{k-i}=0$

If CE has $k$ distinct roots $r_i$, then the solution: $a_n=\sum\limits_{i=1}^k \alpha_ir_i^n$

**The Case of Degenerate Roots in General**：

Suppose there are $t$ roots $r_1,\cdots, r_t$ with multiplicities $m_1,\cdots,m_t$. Then the solution:

**Linear Nonhomogeneous Recurrence Relations**：

$a_n=F(n)+\sum\limits_{i=1}^kc_ia_{n-i}$

- Solve $a_n=\sum\limits_{i=1}^kc_ia_{n-i}$ and get $a_n=h(n)$
- Solve particular solution $p(n)$
- $a_n=p(n)+h(n)$

**Generating Functions**：

$G(x)=a_0+a_1x+\cdots+a_kx^k+\cdots=\sum\limits_{k=0}^{\infty}a_kx^k$

**Examples of Generating Functions**：

$G(x)=1/(1-x)$ for $|x|<1$

$1,1,1,1,1,\cdots$

$G(x)=1/(1-ax)$ for $|ax|<1$

$1,a,a^2,a^3,a^4,\cdots$

$G(x)=1/(1-x)^2$ for $|x|<1$

$1,2,3,4,5,\cdots$

$G(x)=1/(1-ax)^2$ for $|ax|<1$

$1,2a,3a^2,4a^3,5a^4,\cdots$

**Operations of Generating Functions**：

Let $f(x)=\sum\limits_{k=0}^{\infty}a_kx^k$, and $g(x)=\sum\limits_{k=0}^{\infty}b_kx^k$

Then

**Convolution Rule**：

Let $A(x)$ be the generating function for selecting items from a set $A$, and let $B(x)$ be the generating function for selecting items from a set $B$ disjoint from $A$. Then the generating function for selecting items from the union $A ∪ B$ is the product $A(x) \cdot B(x)$.

e.g. Number of ways to select $n$ balls with $k$ colors.

$D(x)=1/(1-x)^k$, $d_n=[x^n] (1/(1-x)^k)=\left(\begin{array}{c}n+k-1 \\n\end{array}\right)$

**Useful Generating Functions**：

$\begin{aligned}

(1+x)^{n} & = \sum_{k=0}^{n} C(n, k) x^{k} \\

(1+a x)^{n} & = \sum\limits_{k=0}^{n} C(n, k) a^{k} x^{k} \\

\left(1+x^{r}\right)^{n} & = \sum\limits_{k=0}^{n} C(n, k) x^{r k} \\

\frac{1-x^{n+1}}{1-x} & = \sum\limits_{k=0}^{n} x^{k} = 1+x+x^{2}+\cdots+x^{n} \\

\frac{1}{1-x} & = \sum\limits_{k=0}^{\infty} x^{k} = 1+x+x^{2}+\cdots \\

\frac{1}{1-a x} & = \sum\limits_{k=0}^{\infty} a^{k} x^{k} = 1+a x+a^{2} x^{2}+\cdots \\

\frac{1}{1-x^{r}} & = \sum\limits_{k=0}^{\infty} x^{r k} = 1+x^{r}+x^{2 r}+\cdots \\

\frac{1}{(1-x)^{2}} & = \sum\limits_{k=0}^{\infty}(k+1) x^{k} = 1+2 x+3 x^{2}+\cdots \\

\frac{1}{(1-x)^{n}} & = \sum\limits_{k=0}^{\infty} C(n+k-1, k) x^{k} \\

\frac{1}{(1+x)^{n}} & = \sum\limits_{k=0}^{\infty} C(n+k-1, k)(-1)^{k} x^{k} \\

\frac{1}{(1-a x)^{n}} & = \sum\limits_{k=0}^{\infty} C(n+k-1, k) a^{k} x^{k} \\

e^{x} & = \sum\limits_{k=0}^{\infty} \frac{x^{k}}{k !} = 1+x+\frac{x^{2}}{2 !}+\frac{x^{3}}{3 !}+\cdots \\

\ln (1+x) & = \sum\limits_{k=0}^{\infty} \frac{(-1)^{k+1} x^{k}}{k} = x-\frac{x^{2}}{2}+\frac{x^{3}}{3}-\frac{x^{4}}{4}+\cdots

\end{aligned}$

**r-Combinations from a Set**：

An n-combination with **repetition allowed**, or a multiset of size $n$, chosen from a set of $k$ elements, is an unordered selection of elements with repetition allowed.

number of n-combinations: $C(n+k-1,n)$

# Chapter 12 - Relation

**Properties of Relations**：

Reflexive Relation：$\forall a\in A$, $(a,a)\in R$

Irreflexive Relation：$\forall a\in A$, $(a,a)\notin R$

- Symmetric Relation：$\forall a,b\in A$, $(a,b)\in R→(b,a)\in R$
Antisymmetric Relation：$\forall a,b\in A$, $(a,b)\in R\wedge (b,a)\in R→a=b$

Transitive Relation：$\forall a,b,c\in A$, $(a,b)\in R\wedge (b,c)\in R→(a,c)\in R$

**Combining Relations**：

Using set operations.

**Composite of Relations**：

$(a,b)\in R$, $(b,c)\in S$, then $(a,c)\in S\circ R$

The powers $R^n$, for $n=1,2,3,\cdots$, is defined inductively by

$R^1=R$ and $R^{n+1}=R^n\circ R$

The relation $R$ on a set $A$ is transitive IFF $R^n\subseteq R$ for $n=1,2,3,\cdots$

**Number of Reflexive Relations**：

The number of reflexive relations on a set $A$ with $|A|=n$ is $2^{n(n-1)}$

Proof: $n$ diagonal elements fixed, the other $n(n-1)$ elements are free to choose.

**Representing Relations**：

explicit list/table, function $f:D→\{T,F\}$, 01 matrix, directed graph…

**Closures of Relations**：

Let $R$ be a relation on a set $A$. A relation $S$ on $A$ with property $P$ is called the closure of $R$ with respect to $P$ if $S$ is subset of every relation $Q$ ($S\subseteq Q$) with property $P$ that contains $R$ ($R\subseteq Q$).

$S$ is the minimal set containing $R$ satisfying the property $P$.

- reflexive closures
- symmetric closures
- transitive closures

**Path Length**：

Let $R$ be relation on a set $A$. There is a path of length $n$ from $a$ to $b$ IFF $(a,b)\in R^n$.

Proof by induction.

Let $A$ be a set with $n$ elements, and $R$ a relation on $A$. If there exists a path from $a$ to $b$ with $a\ne b$, then there exists a path of length $\le n-1$.

**Connectivity Relation**：

Let $R$ be a relation on a set $A$. The connectivity relation $R^\star$ consists of all pairs $(a,b)$ such that there is a path (of any length) between $a$ and $b$ in $R$.

The transitive closure of a relation $R$ equals the connectivity relation $R^\star$.

Proof:

$R^\star$ is transitive.

$(a,b)\in R^\star$ and $(b,c)\in R^\star$, then there are paths from $a$ to $b$ and from $b$ to $c$ in $R$. Thus, there is a path from $a$ to $c$ in $R$. This means that $(a,c)\in R^\star$.

$R^\star\subseteq S$ whenever $S$ is a transitive relation containing $R$.

Suppose that $S$ is a transitive relation containing $R$.

Then $S^n$ is also transitive and $S^n\subseteq S$.

We have $S^\star\subseteq S$. Thus $R^\star\subseteq S^\star\subseteq S$.

**Transitive Closure Algorithm**：

Roy-Warshall Algorithm ($\Theta(n^3)$)

1 | // computes R* ith zero-one matrices |

**n-ary Relations & Relational Databases**：

domains, degree, functional, primary key, composite key, selection, projection, join…

**Equivalence Relation**：

A relation $R$ on a set $A$ is called an equivalence relation if it is **reflexive**, **symmetric** and **transitive**.

**Equivalence Class**：

Let $R$ be an equivalence relation on a set $A$. The set of all elements that are related to an element $a$ of $A$ is called the equivalence class of $a$, denoted by $[a]_R$. When only on relation is considered, we use the notation $[a]$.

Let $R$ be an equivalence relation on a set $A$. The following statements are equivalent:

- $a\ R\ b$
- $[a]=[b]$
- $[a]\cap[b]\ne0$

Proof:

1→2: Prove $[a]\subseteq[b]$ and $[b]\subseteq[a]$

2→3: $[a]$ is not empty ($R$ reflexive)

3→1: $\exists c$ s.t. $c\in[a]$ and $c\in [b]$

**Partition of a set**：

Let $S$ be a set. A collection of nonempty subsets of $S$ $A_1,A_2,\cdots,A_k$ is called a partition of $S$ is

$A_i\cap A_j=\emptyset$, $i\ne j$ and $S=\bigcup\limits_{i=1}^{k}A_i$

**Equivalence Classes and Partitions**：

Let $R$ be an equivalence relation on a set $A$. Then union of all th equivalence classes of $R$ is $A$:

The equivalence classes form a partition of $A$.

Let $\{A_1,A_2,\cdots,A_i,\cdots\}$ be a partition of $S$. Then there is an equivalence relation $R$ on $S$, that has the sets $A_i$ as its equivalence classes.

**Partial Ordering**：

A relation $R$ on a set $S$ is called a partial ordering, if it is **reflexive**, **antisymmetric** and **transitive**. A set $S$ together with a partial ordering $R$ is called a poset, denoted by $(S,R)$. Members of $S$ are called elements of the poset.

**Comparability**：

The elements $a$ and $b$ of a poset $(S,≼)$ are comparable if either $a≼b$ or $b≼a$. Otherwise, $a$ and $b$ are called incomparable.

**Total Ordering**：

If $(S,≼)$ is a poset and every two elements of $S$ are comparable, $S$ is called a **totally ordered** or **linearly ordered set**, and $≼$ is called a **total order** or a **linear order**. A totally ordered set is also called a **chain**.

**Lexicographic Ordering**：

Given two posets $(A_1,≼_1)$ and $(A_2,≼_2)$, the lexicographic ordering on $A_1\times A_2$ is defined by specifying that $(a_1,a_2)$ is less than $(b_1,b_2)$, i.e., $(a_1,a_2)≼(b_1,b_2)$, either if $a_1≺_1b_1$ or if $a_1=b_1$ then $a_2≼_2b_2$.

**Hasse Diagram**：

……

**Maximal and Minimal Elements**：

$a$ is a maximal (resp. minimal) element in poset $(S, ≼)$ is there is no $b\in S$ such that $a ≺ b$ (resp. $b ≺ a$).

**Greatest and Least Elements**：

$a$ is the greatest (resp. least) element of the poset $(S, ≼)$ if $b ≼ a$ (resp. $a ≼ b$) for all $b\in S$.

**Upper Bound and Lower Bound**：

$u\in S$ is called an upper bound (resp. lower bound) of $A$ if $a ≼ u$ (resp. $u ≼ a$) for all $a\in A$.

$x\in S$ is called the least upper bound (resp. greatest lower bound) of $A$ if $x$ is an upper bound (resp. lower bound) that is less than any other upper bound (resp. greater than any other lower bound) of $A$.

**Well-Ordered Set**：

$(S, ≼)$ is a well-ordered set if it is a poset such that $≼$ is a total ordering and every non empty subset of $S$ has a least element.

**The Principle of Well-Ordered Induction**：

Suppose that $S$ is a well-ordered set. Then $P(x)$ is true for all $x\in S$, if

Inductive Step: For every $y\in S$, if $P(x)$ is true for all $x\in S$ with $x ≺ y$, then $P(y)$ is true.

**The reason for no base step**: For the least element $x_0$, the precedent “P(x) is true for all $x\in S$ with $x ≺ x_0$” is itself false, by **vacuous proof**, $P(x_0)$ is true.

**Lattices**：

A poset in which every pair of elements has both a least upper bound and a greatest lower bound is called a lattice.

**Topological Sorting**：

Given a partial ordering $R$, find a total ordering $≼$ such that $a≼b$ whenever $a\ R\ b$. $≼$ is said **compatible** with $R$.

# Chapter 13 - Graph

**Definition of a Graph**：

A graph $G=(V,E)$ consists of a nonempty set $V$ of vertices and a set $R$ of edges. Each edge has either one or two vertices associated with it, called its endpoints. An edge is said to be incident to its endpoints.

**Simple graph**：

A graph in which at most one edge joins each pair of distinct vertices and no edge joins a vertex to itself.

**multigraph**：

Graphs that may have multiple edges connecting the same vertices.

**pseudograph**：

Graphs that may include loops, and possibly multiple edges connecting the same pair of vertices or a vertex to itself.

**Undirected Graphs**：

adjacent(neighbors), neighborhood, degree…

Handshaking Theorem: If $G=(V,E)$ is an undirected graph with $m$ edges, then $2m=\sum\limits_{v\in V}deg(v)$.

An undirected graph has an even number of vertices of odd degree.

**Directed Graphs**：

adjacent from, adjacent to, in-degree $deg^-(v)$, out-degree $deg^+(v)$

$|E|=\sum\limits_{v\in V}deg^-(v)=\sum\limits_{v\in V}deg^+(v)$

**Complete Graphs**：

A complete graph on $n$ vertices, denoted by $K_n$, is the simple graph that contains exactly one edge between each pair of distinct vertices.

**Cycles**：

A cycle $C_n$ for $n \ge 3$ consists of $n$ vertices $v_1, v_2,\cdots, v_n$, and edges $\{v_1,v_2\},\{v_2,v_3\},\cdots,\{v_{n-1},v_n\},\{v_n,v_1\}$.

**Wheels**：

A wheel $W_n$ is obtained by adding an additional vertex to a cycle $C_n$.

**N-dimensional Hypercube**：

An n-cube $Q_n$ is a graph with $2^n$ vertices representing all bit strings of length $n$, where there is an edge between two vertices that differ in exactly one bit position.

**Bipartite Graphs**：

A simple graph $G$ is bipartite if $V$ can be partitioned into two disjoint subsets $V_1$ and $V_2$ such that every edge connects a vertex in $V_1$ and a vertex in $V_2$.

**Complete Bipartite Graphs**：

A complete bipartite graph $K_{m,n}$ is a graph that has its vertex set partitioned into two subsets $V_1$ of size $m$ and $V_2$ of size $n$ such that there is an edge from every vertex in $V_1$ to every vertex in $V_2$.

**Bipartite Graphs and Matchings**：

A matching is a subset of $E$ such that no two edges are incident with the same vertex.

A maximum matching is a matching with the largest number of edges.

A matching $M$ in a bipartite graph $G=(V,E)$ wth bipartition $(V_1,V_2)$ is a complete matching from $V_1$ to $V_2$ if every vertex in $V_1$ is the endpoint of an edge in the matching, i.e., $|M|=|V_1|$.

**Hall’s Marriage Theorem**：

The bipartite graph $G=(V,E)$ with bipartition $(V_1,V_2)$ has a complete matching from $V_1$ to $V_2$ IFF $|N(A)|\ge |A|$ for all subsets $A$ of $V_1$.

“only if”: For every vertex $v\in A$, there is an edge in $M$ connecting $v$ to a vertex in $V_2$. Thus, for all subsets $A$ of $V_1$, there are at least as many vertices in $V_2$ that are neigbors of vertices in $A$ as there are vertices in $A$, $|N(A)|\ge |A|$.

“if”: Use strong induction.

Base step: $|V_1|=1$

Inductive hypothesis: Let $k$ be a positive integer. If $G=(V,E)$ is a bipartite graph ith bipartition $(V_1,V_2)$, and $|V_1|=j\le k$, then there is a complete matching $M$ from $V_1$ to $V_2$ whenever the condition that $|N(A)|\ge |A|$ for all $A\subseteq V_1$ is met.

Inductive step: suppose that $H=(W,F)$ is a bipartite graph with bipartition $(W_1,W_2)$ and $|W_1|=k+1$

Case (Ⅰ): For all integers $j$ with $1\le j\le k$, the vertices in every set of $j$ elements from $W_1$ are adjacent to at least $j+1$ elements of $W_2$.

Find a complete matching from $W_1-\{v\}$ to $W_2-\{w\}$, then match $v$ to $w$.

Case (Ⅱ): For some integer $j$ with $1\le j\le k$, there is a subset $W_1’$ of $j$ vertices such that there are exactly $j$ neighbors of these vertices in $W_2$.

Let $W_2’$ be the set of these neighbors. Then by i.h., there is a complete matching from $W_1’$ to $W_2’$. Now consider the graph $K=(W_1-W_1’,W_2-W_2’)$. We will show that the condition $|N(A)|\ge |A|$ is met for all subsets $A$ of $W_1-W_1’$.

If not, there is a subset $B$ of $t$ vertices with $1\le t\le k+1-j$ such that $|N(B)|<|B|$, contradiction.

Then there is a complete matching for $K$, and thus a complete matching for $G$.

**Subgraphs**：

A subgraph of a graph $G=(V,E)$ is a graph $(W,F)$, where $W\subseteq V$ and $F\subseteq E$. A subgraph $H$ of $G$ is a proper subgraph of $G$ if $H\ne G$.

**Union of Simple Graphs**：

Simple graph: $G_1\cup G_2=(V_1\cup V_2, E_1\cup E_2)$

**Representation of Graphs**：

adjacency lists, adjacency matrices, and incidence matrices.

**Isomorphism of Graphs**：

The simple graphs $G_1=(V_1,E_1)$ and $G_2=(V_2,E_2)$ are isomorphic if there is a **bijection** from $V_1$ to $V_2$ with the property that $a$ and $b$ are adjacent in $G_1$ IFF $f(a)$ and $f(b)$ are adjacent in $G_2$, for all $a$ and $b$ in $V_1$. Such a function is called an isomorphism.

Useful graph invariants: the number of vertices, number of edges, degree sequence, etc.

**Path**：

Let $n$ be a nonnegative integer and $G$ an undirected graph. A path of length $n$ from $u$ to $v$ in $G$ is a sequence of $n$ edges $e_1,e_2,\cdots,e_n$ of $G$ for which there exists a sequence $x_0=u,x_1,\cdots,x_{n-1},x_n=v$ of vertices such that $e_i$ has the endpoints $x_{i-1}$ and $x_i$ for $i=1,\cdots,n$.

A path is **simple** if it does not contain the same edge more than once.

**Circuit**：

The path is a circuit if it begins and ends at the same vertex, i.e., if $u=v$ and has the length greater than $0$.

**Simple Path Existence Lemma**：

If there is a path between two distinct vertices $x$ and $y$ in graph $G$, then there is a simple path between $x$ and $y$ in $G$. (Just delete cycles/loops.)

**Connected Components**：

A connected component of a graph $G$ is a connected subgraph of $G$ that is not a proper subgraph of another connected subgraph of $G$.

**Connectedness in Directed Graphs**：

A directed graph is strongly connected if there is a path from $a$ to $b$ and a path from $b$ to $a$ whenever $a$ and $b$ are vertices in the graph.

A directed graph is weakly connected if there is a path between every two vertices in the underlying undirected graph.

**Cut Vertices and Cut Edges**：

……

A set of edges $E’$ is called an edge cut of $G$ if the subgraph $G-E’$ is disconnected. The edge connectivity $\lambda(G)$ is the minimum number of edges in an edge cut of $G$.

**Paths and Isomorphism**：

The existence of a simple circuit of length $k$ is isomorphic invariant. In addition, paths can be used to construct mappings that may be isomorphisms.

**Counting Paths between Vertices**：

Let $G$ be a graph with adjacency matrix $A$ with respect to the ordering $v_1, v_2,\cdots, v_n$ of vertices. The number of different paths of length r from $v_i$ to $v_j$ , where $r > 0$ is positive, equals the $(i, j)$-th entry of $A^r$.

Proof by induction:

$A^{r+1}=A^rA$, the $(i,j)$-th entry of $A^{r+1}$ equals $b_{i1}a_{1j}+b_{i2}a_{2j}+\cdots+b_{in}a_{nj}$, where $b_{ik}$ is the $(i,k)$-th entry of $A^r$.

**Euler Paths and Circuits**：

An Euler circuit in a graph $G$ is a simple circuit containing every edge of $G$.

A connected multigraph with at least two vertices has an Euler circuit IFF each of its vertices has even degree.

An Euler path in $G$ is a simple path containing every edge of $G$.

A connected multigraph has an Euler path but not an Euler circuit IFF it has exactly two vertices of odd degree.

**Hamilton Paths and Circuits**：

A simple path in a graph $G$ that passes through every vertex exactly once is called a Hamilton path.

A simple circuit in a graph $G$ that passes through every vertex exactly once is called a Hamilton circuit.

**Sufficient Conditions for Hamilton Circuits**：

**Dirac’s Theorem**： If $G$ is a simple graph with $n\ge 3$ vertices such that the degree of every vertex in $G$ is $\ge n/2$, then $G$ has a Hamilton circuit.

**Ore’s Theorem**： If $G$ is a simple graph with $n\ge 3$ vertices such that $deg(u)+deg(v)\ge n$ for every pair of nonadjacent vertices, then $G$ has a Hamilton circuit.

**Shortest Path Problems**：

Dijkstra-$O(v^2)$, Fredman & Tarjan-$O(e+v\log v)$, Bellman-Ford-$O(ev)$…

**Planar Graphs**：

A graph is called planar if it can be drawn in the plane without any edge crossing. Such a drawing is called a planar representation of the graph.

**Euler’s Formula**：

Let $G$ be a connected planar simple graph with $e$ edges and $v$ vertices. Let $r$ be the number of regions ina planar representation of $G$. Then $r=e-v+2$.

Proof by induction.

**The Degree of Regions**：

The degree of a region is defined to be the number of edges on the boundary of this region. When an edge occurs twice on the boundary, it contributes two to the degree.

**Corollaries of Planar Graphs**：

**Corollary 1**： If $G$ is a connected planar simple graph with $e$ edges and $v$ vertices, where $v\ge3$, then $e\le 3v-6$.

The degree of every region is at least 3.

The sum of the degrees of the regions is exactly twice the number of edges in the graph.

**Corollary 2**：If $G$ is a connected planar simple graph, then $G$ has a vertex of degree not exceeding 5.

- Proof by contradiction using Corollary 1 and Handshaking Theorem.

**Corollary 3**：In a connected planar simple graph has $e$ edges and $v$ vertices with $v\ge3$ and no circuits of length 3, then $e\le2v-4$.

- The degree of every region is at least 4. (no circuit of length 3)

**Kuratowski’s Theorem**：

If a graph is planar, so will be any graph obtained by removing an edge $\{u, v\}$ and adding a new vertex $w$ together with edges $\{u,w\}$ and $\{w, v\}$. Such an operation is called an **elementary subdivision**.

The graphs $G_1 = (V_1, E_1 )$ and $G_2 = (V_2, E_2 )$ are called **homomorphic** if they can be obtained from the same graph by a sequence of elementary subdivisions.

A graph is nonplanar IFF it contains a subgraph homomorphic to $K_{3,3}$ or $K_5$.

**Graph Coloring**：

A coloring of a simple graph is the assignment of a color to each vertex of the graph so that no two adjacent vertices are assigned the same color.

The chromatic number of a graph is the least number of colors needed for a coloring of this graph, denoted by $\chi(G)$.

**Four-color theorem**：

The chromatic number of a planar graph is no greater than 4.

**Six Color Theorem**：

The chromatic number of a planar graph is no greater than 6.

**Proof by induction**. (w.l.o.g., assume that the graph is connected)

**Basic step**: For a single vertex, pick an arbitrary color.

**Inductive hypothesis**: Assume that every planar graph with $k\ge1$ or fewer vertices can be 6-colored.

**Inductive step**: Consider a planar graph with $k+1$ vertices. Using **Corollary 2** (the graph has a vertex of degree 5 or fewer). Remove this vertex, by i.h., we can color the remaining graph with 6 colors. Put the vertex back in. Since there are at most 5 colors adjacent, so we have at least one color left.

**Five Color Theorem**：

The chromatic number of a planar graph is no greater than 5.

**Proof by induction**. (w.l.o.g., assume that the graph is connected)

**Basic step**: For a single vertex, pick an arbitrary color.

**Inductive hypothesis**: Assume that every planar graph with $k\ge1$ or fewer vertices can be 5-colored.

**Inductive step**: Consider a planar graph with k + 1 vertices. Using **Corollary 2** (the graph has a vertex of degree 5 or fewer). Remove this vertex, by i.h., we can color the remaining graph with 5 colors. Put the vertex back in.

Case (Ⅰ): If the vertex has degree less than 5, or if it has degree 5 and only $\le 4$ colors are used for vertices connected to it, we can pick an available color for it.

Case (Ⅱ): We make a subgraph out of all the vertices colored 1 or 3. If the adjacent vertex colored 1 and the adjacent vertex colored 3 are not connected by a path in the subgraph.

On the other hand, if the vertices colored 1 and 3 are connected via a path in the subgraph, we do the the same for the vertices colored 2 and 4. Note that this will be a disconnected pair of subgraphs, separated by a path connecting the vertices colored 1 and 3.

# Chapter 14 - Tree

**Tree**：

A tree is a connected undirected graph with no simple circuits.

An undirected graph is a tree IFF there is a unique simple path between any two of its vertices.

A rooted tree is a tree in which one vertex has been designated as the root and every edge is directed away from the root.

parent, child, sibling, ancestor, descendant, leaf, internal vertex, subtree…

**m-Ary Trees**：

A rooted tree is called an m-ary tree if every internal vertex has no more than $m$ children.

The tree is called a **full** m-ary tree if every internal vertex has exactly $m$ children.

In particular, an m-ary tree with $m = 2$ is called a binary tree.

A binary tree is an ordered rooted tree where the children of each internal vertex are ordered.

In a binary tree, the first child is called the left child, and the second child is called the right child.

left subtree, right subtree

**Counting Vertices in a Full m-Ary Trees**：

A full m-ary tree with $i$ internal vertices has $n = mi + 1$ vertices. Leaves number $ℓ=n-i$.

**Level and Height**：

The level of a vertex $v$ in a rooted tree is the length of the unique path from the root to this vertex.

The height of a rooted tree is the maximum of the levels of the vertices.

A rooted m-ary tree of height $h$ is balanced if all leaves are at levels $h$ or $h − 1$. (differ no greater than 1)

**The Number of Leaves**：

There are at most $m^h$ leaves in an m-ary tree of height $h$.

If an m-ary tree of height $h$ has ℓ leaves, then $h \ge ⌈\log_m ℓ⌉$. If the m-ary tree is full and balanced, then h = $⌈\log_mℓ⌉$.

**Tree Traversal**：

preorder traversal, inorder traversal, postorder traversal.

expression trees, prefix notation, infix notation, postfix notation.

**Catalan Numbers**：

$C_0=C_1=1$

$C_n=\sum\limits_{i=0}^{n-1}C_iC_{n-i-1}=\frac{1}{n+1}\left(\begin{array}{c}2n \\n\end{array}\right)=\left(\begin{array}{c}2n \\n\end{array}\right)-\left(\begin{array}{c}2n \\n-1\end{array}\right)$

The number of 01 sequences using $n$ ones and $n$ zeros such that the number of ones is no less than the number of zeros in any prefix subsequence.

The number of full binary trees with $2n+1$ vertices.

The number of binary trees with $n$ vertices.

**Spanning Trees**：

Let $G$ be a simple graph. A spanning tree of $G$ is a subgraph of $G$ that is a tree containing every vertex of $G$.

A simple graph is connected IFF it has a spanning tree.

**DFS, BFS**：

……

**Minimum Spanning Trees**：

Prim’s Algorithm($O(e\log v)$), Kruskal’s Algorithm($O(e\log e)$).

# Chapter 15 - P, NP and NPC Problems

**Class NP vs. Class P**：

**P**： decision problems solvable in polynomial time

**NP**： decision problems with certificates verifiable in polynomial time (polynomial time verification)

**Satisfiability Problem(NP)**：

To determine whether a Boolean formula is satisfiable or not.

**2SAT Problem(P)**：

To determine whether a 2-CNF formula is satisfiable or not.

Using path searching (polynomial-time decidable), construct edges using “→”.

A 2-CNF formula is **unsatisfiable** IFF there exists a variable $x$ such that:

- there is a path from $x$ to $\neg x$ in the graph $G$
- there is a path from $\neg x$ to $x$ in the graph $G$

**Polynomial-Time Reduction & The Class NP-Complete**：

see Chapter 6.

**Cook’s Theorem**：

SAT $\in$ NPC.

3SAT $\le_P$ DCLIQUE $\le_P$ DVC

**Clique**：

A clique is a complete subgraph of $G$.

The Problem CLIQUE

Find a clique of maximum size in a graph $G$.

The Problem DCLIQUE

Given an undirected graph G and an integer $k$, determine whether $G$ has a clique of size $k$.

DCLIQUE $\in$ NP： certificate $O(|V^2|)$

**3SAT $\le_{P}$ DCLIQUE**：

For the $k$ clauses input to 3SAT, draw literals as vertices, and all edges between vertices such that:

- across clauses only
- not between $x$ and $\neg x$

The reduction takes polynomial time: A satisfiable assignment $⇌$ a clique of size $k$

**Vertex Cover**：

A vertex cover of $G$ is a set of vertices such that every edge in $G$ is incident at at least one of these vertices.

The Vertex Cover Problem (VC)

Given a graph $G$, find a vertex cover of $G$ of minimum size.

The Problem DVC

Given a graph $G$ and an integer $k$, determine whether $G$ has a vertex cover of with $k$ vertices.

DVC $\in$ NP： certificate $O(ke)=O((n+e)^2)$

**DCLIQUE $\le_{P}$ DVC**：

Start with the graph $G=(V,E)$ input of the DCLIQUE problem.

Construct the complement graph $\bar G=(V,\bar E)$ by only considering the missing edges from $E$.

The reduction takes polynomial time: A clique of size $k$ in $G$ $⇌$ a vertex cover of size $|V|-k$ in $\bar G$

**Approximate Vertex Cover**：

Approx-Vertex-Cover is a 2-approximation algorithm, i.e., $\frac{|C|}{|C^\star|}\le 2$.

Proof:

The set of edges picked by this algorithm is a maximal-maching $M$: no two edges touch each other.

The potimal vertex cover $C^\star$ must cover every edge in $M$, so $|C^\star|\ge |M|$. The algorithm returns a vertex set of size $2|M|$. Therefore, we have

.
